Economy, Heated,
Drum Mounted Parts Washer

Designed for use with aqueous based cleaning solutions

Contact us:
EnviroSan Products Ltd.

"designed to help protect the environment"

The sensible solution,
designed to Last!

• Corrosion resistant heavy-duty pump
• Flexible spigot
• Flo-thru brush with adjustable fluid control
• Designed for easy servicing, heater pump and thermostat module can be removed in minutes from sink basin
• Heavy duty vacuum formed sink
• Liquid level sight tube
• Operating fluid capacity 20-25 Gals.
• Automatic thermostat preset to 110 degrees
• Ground fault circuit interrupter for added safety
• 115 volts, 15 amps
• Individual switches for heater and pump

Options:

• 930 - 1 Stainless Steel Lid
• 930 - 2 Stainless Steel Parts Tray
• 930 - 3 Stainless Portable Tray with 5" Casters
• P-26 Filter System

Tank Dimensions: Width 23", Length 34", Depth  9", Weight: 57 Lbs.

  Environmental Parts Washer Fluid

...with long-term rust inhibitor

Front Loading Jet Washers

                   ...designed for use with aqueous based cleaning solutions

C9400 Features:

Overall Size: 50 "Lx42"W 65" H
Voltage: 220 V, 45 Amps
Weight: 800 Lbs
Large 30" Turntable
1.5 H.P. Pump with Stainless Steel Impeller
6.0 KW Heating Capacity (1 Heater)
Adjustable Cycle Timer (0-60 minutes)
Gasket Free Front Door
Large 65 Gallon Fluid Capacity
11.5 inch Stainless Steel Disc Skimmer
Large 500Lb Weight Capacity
Friction Turntable Drive
Removable Tree Rack
Portable with 4 casters

C9600 Features:

Overall Size: 50 "Lx42" Wx65" H
Voltage: 220 V, 60 Amps
Weight: 920 Lbs
Large 30" Turntable
40" Inside Working Height
3.0 H.P. Pump with Stainless Steel Impeller
9.0 KW Heating Capacity (2 Heaters)
Adjustable Cycle Timer (0-60 minutes)
Adjustable Heat Timer, allows you to keep solution hot overnight
Stainless Steel, Gasket Free Front Door
Large 85 Gallon Fluid Capacity
11.5 inch Stainless Steel Disc Skimmer
Large 500Lb Weight Capacity
Friction Turntable Drive will not break if part becomes lodged
Liquid Level Sensor automatically turns off heaters before they burn out
Removable Tree Rack, Standard
Portable with 4 casters
Stainless Steel nozzles for lower maintenance costs
Centre Spray Bar folds down for Cleaning of Smaller Parts

Use biodegradable degreaser.

Top Load Jet Washer

Designed to clean parts automatically in less than 15 minutes...
                      ...designed for use with aqueous based cleaning solutions.

Features:

Turntable: 24"
Inside working height: 23"
Pump: High volume 1.0 H.P. with stainless steel impeller
Heating capacity: 4.5 KW
Timer: Adjustable cycle from 0 to 60 minutes
Lid: Stainless steel gasket-less, for maintenance free operation
Reservoir capacity: 30 gallons
Friction turntable drive
Liquid level sensor
Removable tree rack
Moveable top arm for easy loading and unloading

Dimensions, Overall Size: 36" L x 34" W x 50" H
Voltage: 220V, 30 AMPS
Weight: 425 lbs.

Economy Models

Model: 20

• Rugged welded steel
• Convenient removable work shelf
• Parts basket for shaking small parts in solvent.
• Self-Latching fuse linked fire cover.
• 110 Volts / 60 Cycle Solvent Pump
• Recirculates 10-12 Litre/Min of solvent
• Tank Capacity: 20 Gallons
• Solvent Capacity: 12 Gallons
• ULC Approved

Models:
260, 265 & 270

• Use solvent, biodegradable SOLUTION 2000™ or Rust inhibited SOLUTION 2003
• UL - CSA approved electric pump 110v.
• Durable powder coat paint
• Fire safety lid
• Flo-thru brush optional
• 16 and 18 gauge steel construction
• Filter pad to keep sludge and dirt from pump (C260)
• Parts shelf (Model C260)

• Available with flo-thru brush.

Flo-thru brush not included.

Portable Parts Cleaner

Air-Operated, Rotating

• For use with solvents or carb. cleaner
• Cleans small parts while you do other jobs
• Lever lock ring seals heavy duty reversing air-motor to top of pail

Model155 - Model 255

Pail and Drum are not included

Parts Cleaners

Model: 300

Models: 310 & 390

Features:

• Fire safety lid

• Electrical pump located in the middle of pail

• Durable powder coat paint

• 16 and 18 gauge construction

• Flexible metal hose

• Flo-Thru brush

• CSA approved

• Solvent comes out of metal hose and Flo-Thru brush at the same time

• Parts tray with drain hose - keeps small parts from being lost

• Available in 220 v. - 50 or 60 cycle

• Unique water trap when petroleum solvent in use, 1" of water in bottom of pail to trap grease, oil and dirt. Stops solvent from mixing with grease and oil. Solvent lasts longer

• Model C310 and C390 comes with 10 gal./45.5 L. pail for use in busy shops

• Use Solvent or Biodegradable SOLUTION 2000™ or 2003

34 x 19 x 13.5
18 x 18 x 18

40 x 38 x 22
18 x 18 x 18
